Basic Info.
Model NO.
1MW 3MW 5MW solar power storage off grid batteries
Keyword
Customized 1mwh 5mwh Megawatt Container
Cycle Life
>2000 Cycles
Warranty
3months-1year
Battery Size
300kw 500kw 1MW 3MW 5MW 10MW
BMS System
Customized
Features
Deep Cycle Battery
Name
Battery Energy Storage System Container
Weight
1000+ Kg
Power Grid Frequency Range
50Hz / 60Hz ± 2.5Hz
Nominal Capacity
100ah
Certification
ISO9001, ISO14001, OHSAS18001, RoHS, Tlc, etc
Trademark
Tycorun
Origin
Guangdong, China
Production Capacity
10000 Unit/Units Per Month
Product Description
Tycorun Customized 1MWH 5MWH Megawatt outdoor solar LiFePO4 lithium ion battery energy storage system container for Industry
| Name | Tycorun Customized 1MWH 5MWH Megawatt outdoor solar LiFePO4 lithium ion battery energy storage system container for Industry | ||
| Function | Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies | ||
| AC Input Voltage | 400 / 480 VAC | ||
| Power Factor | -1~+1 | ||
| AC Input Frequency | 50Hz / 60Hz ± 2.5Hz | ||
| Max Charge Power | 100 kW | ||
| Max Efficiency | 98.2% | ||
| Cycle Life | >2000 Cycles @ 0.2C Charge/Discharge at 100%DOD,End of Life 70% Capacity | ||
| Certification | CE, TUV, IEC, UL, ETL | ||
| AC Output (Discharging) | |||
| Rated AC Output Power | 100kW | ||
| AC Output Voltage | 400 / 480 VAC | ||
| AC Output Frequency | 50 / 60Hz ± 2.5Hz | ||
| Max Efficiency | 98.2% | ||
| PV Input (Optional) | |||
| Max PV Input Power | 110kWp | ||
| MPPT Input Voltage Range | 450~850 VDC | ||
| MPPT Number | 1 / 2 | ||
| MPPT Efficiency | 99.50% | ||
| Unique Function | |||
| Grid-Level Function | Peak shaving and valley filling for electric network | ||
| Operational Mode | Off-Grid Mode / On-Grid Mode / On & Off grid Mode (Optional) | ||
| UPS Function | YES | ||
| Communication Interface | LAN, RS485, CAN | ||
| General | |||
| Working Condition | Temperature range -20~50ºC, Humidity range 0~95% | ||
| Noise and Altitude | 70dB, <3000m | ||
| Size of PS100kW-1050kWh | 20 foot container | ||
| Weight of PS100kW-1050kWh | 15 tons | ||
Q:What is the MOQ ?
A: 10pcs/set small order to test quality.
Q: Can I place an sample order to test quality?
A: Sure!
Q: Can I get a lower price if I order large quantities?
A:Yes, cheaper prices with bulk orders.
Q: Can I get the pre-production sample?
A: Yes, we will send you sample, after you confirm, then we will start production.
Q: When you ship my order?
A: Normally 3-5days after receiving your payment, but it can be negotiated based on order qty an production schedule.
Q: What mode of payment do you usually accept?
A: Transfer, Western Union, Money Gram,Trade Assurance etc. are all accept.
Q: How can you guarantee the production quality ?
A: Our engineer has 20 years experience in mold design, we know the detailed performance and specifications of silicone materials,we also can meet your special requirements. We can provide one-stop service, from the mold design, mold manufacturing and production delivery.
A: 10pcs/set small order to test quality.
Q: Can I place an sample order to test quality?
A: Sure!
Q: Can I get a lower price if I order large quantities?
A:Yes, cheaper prices with bulk orders.
Q: Can I get the pre-production sample?
A: Yes, we will send you sample, after you confirm, then we will start production.
Q: When you ship my order?
A: Normally 3-5days after receiving your payment, but it can be negotiated based on order qty an production schedule.
Q: What mode of payment do you usually accept?
A: Transfer, Western Union, Money Gram,Trade Assurance etc. are all accept.
Q: How can you guarantee the production quality ?
A: Our engineer has 20 years experience in mold design, we know the detailed performance and specifications of silicone materials,we also can meet your special requirements. We can provide one-stop service, from the mold design, mold manufacturing and production delivery.
